Dive Survey vessel

For charter or sale

Contact us for Charter options or purchase price

Specification

Builder: McTay Marine Limited – Wirral Launched Originally launched in 1989 and completely re-fitted in 2009
Length (LOA): 26.60m
Beam: 5.90m
Draft: 1.8m
Working Displacement: 106 Tonnes
Cruising Speed: 15kts
Maximum Range: 750nm
Operating Code: MCA SCV Category 2 (60miles from safe haven). Category 1 (150 mile dispensation available for specified contract).
Accommodation: Three double cabins and three single cabins providing accommodation for a maximum of 9 beds per shift (max POB 16).
Fuel Capacity: 10 Tonnes

50 ton Jack up Barge €600.000.00    ONO

                                 Specifications:

Barge Size:

15/12/9m x 12 x 1.5m

Spud Legs:

610mm o/d x 20m (20mm wall thickness)

Deckload:

15t / m2

Powerpack Engine:

Deutz F6L912 Aircooled

Hydraulic Oil Capacity:

280litres

Pontoon weight (Each):

7 ton

Jacking Unit weight (Each)

3 ton

Leg (Each)

6 ton

No of Moonpools

2 x 330mm approx.

No of trucks to move

5 (3 x 40ft & 2 x 60ft)

Deck Lifting Capacity

50t

80 ton Jack up barge

€750.000.00 ono

I

                                                        Specifications:

Barge Size:

18m x 12 x 1.5m

Spud Legs:

762mm o/d x 18m / 29m (25mm wall thickness)

Deck load:

15t / m2

Power pack Engine:

Deutz F6L912 Air-cooled

Hydraulic Oil Capacity:

280litres

Pontoon weight (Each):

14 ton

Jacking Unit weight (Each)

5 ton

Leg (Each)

18 ton

No of Moonpools

2 x 330mm approx.

No of trucks to move

10 (8 x 40ft & 2 x 60ft)

Deck Lifting Capacity

80t

For Sale LANDING CRAFT

This landing craft is coded for 8 persons. can be increased to 16 .CAT 2   This Vessel has a reinforced hull on triple bilge keels for doing beach landings.

Electronics Equipment

Koden Marine Chart Plotter

Koden Marine Echo Sounder

Furuno AIS

Koden 4kw Marine Radar

Search & Rescue Directional Finder

Raymarine Loud Hailer

2 x Sailor RT 2048 VHF

Sailor DSC

3 X Icom VHF Hand Held

Furuno NX500 Navtex

Webesto Diesel Engine Heater sand Cabin Heaters

12 V, 110V, 249V Power Outlets

Boats Telephone & Internet

2 x 1000W Directional Search Lights

All LED Lighting

Performance



Main Engines

2 x Yanmar 315HP

Gear Boxes

ZF V-Drives

Propellers

4 Blade

Fuel Capacity

1100  Litres

Range

240 NM Approx

Speed

22 Knots

MCA Coding

Category 2-60 miles from safe haven

HIAB

1Ton – 4m reach

Cargo Capacity

Marine Capstan 3000kg

10 Mtr Fishing -Workboat

Asking price £10,000.00 Laying South coast UK Just painted and waiting for anti-foul. ford saber engine in it.

Back Hoe Dredger for sale


 LOA   55.15 MTR  Beam 15.20 with side pontoons. 11.40 with out

Draft with Excavator 3.136 Deck Load 10T m2. 6x single cabins

Fully refurbished Hitachi EX 1200 Triple boom with long and short stick

Class BV  deep sea,assisted , unrestricted , Year of construction 1997 full refit 2005

Aluminium Work Boats

Landing Craft Work Boats- Built in the UK .made from 5mm thick marine grade DNV approved aluminium material

Building Landing Craft Work boats continuously for the Commercial and Leisure industry.

WB 01.jpg

We can build these boats to your own specification and design, with different style wheel house and cabins.

WB 01.jpg

We can supply all new vessels with choice of Engines. In board or  out board. also with jet drive or prop. we can build to you requirements with a short lead in time. The vessel above around 6 weeks from time of placing order. We can also supply coded and ready to work.

Road Transportable Pontoons

€50.000.00

Newly painted . new anodes new handrails plus Surveyors report

Specification



Vessel Type



Individual Unit Dimensions



Construction Material



Gross Permissible Weight



Draft Unladen

Draft Fully Laden



Freeboard Unladen

Freeboard Fully Laden



Max Deck Loading



Single Unit Net Weight



Additional Information



12 m x 410 mm (dia) Spud Legs

15 m x 410 mm (dia) Spud Legs

Modular Pontoon



16 x 4.12 x 1.7 mts



Steel



42 tonnes



0.45 mts



1.15 mts



1.25 mts



0.56 mts



1.5 tonne Sq. Mt


20 tonnes

9Mtr NATO Tug

SOLD SOLD SOLD SOLD

A versatile heavy duty, shallow draft workboat with Schottle 360 degree drive providing good towing and pushing capability for its size. The engine is an air cooled V12 Deutz, offering around 210 hp with huge amounts of torque, circa 2-ton bollard pull, and surprisingly economical.  Weight is around 7 tons, and it can be craned onto a lorry via a central lifting eye.

Schottle Tug Specification:

LOA:                     9.2 metres

Beam:                  2.4 metres

Depth:                  1.4 metres

Draft                     1.0 metres (max)

Engine:                210hp

Bollard pull:        2.0 tonnes

Service Speed:  9.0 knots

BERKY WEED HARVESTER type 6540

ENGINE

4 CYL PERKINS 1004-40 120HP AT 2300 RPM . 1,419 HOURS FROM NEW



Fuel tank

600 LTR

Hull

LOA 14.2MTR HULL 9.50MTR BEAM 3.00MTR HIGHT 1.25MTR EMPTY WEIGHT 14.400 KG

This vessel is like new as you can see from the pictures in the engine compartment.

Twin Screw Tug- Workboat

£150.000.00

DELIVERY DATE               1978

CLASSIFICATION               MCA Workboat Category 3                          MAIN ENGINES        2 X Caterpillar 3306  284 kW (380 bhp)

GEARBOXES         Twin Disc

 PROPS                  2x Bronze fixed pitch





DECK LAY-OUT



ANCHOR

    1 X 75 kg Piool (High Holding Power)

CHAIN (TOT.)

    200 m shortlink 16 mm U2/Q2

ANCHOR WINCH

    Hand operated

TOWING HOOK

    Mampaey, SWL  50 kN





L O.A.   16.2 m



BEAM    4.9 m



DEPTH  AT SIDES   2.3 m



DRAUGHT AFT   1.8 m



DISPLACEMENT      60 Te



GRT 50.  41



TANK CAPACITIES

FUEL   8.8 m³

FRESH WATER  2.0 m³



BOLLARD PULL AHEAD       5.0 Te

SPEED                             10.0 knots







Accommodation for 4 persons, consisting of one 4 persons cabin, a galley, and sanitary facilities. The Vessel is suited to transport 7 passengers. seated in the wheelhouse.

COMPASS

 Magnetic, Observator

VHF    Icom 423G (DSC)

AIS      Icon MA-500TR



X CORY TUG

£60.000.00

Built 1962
Lister Blackstone Engine 1150hp
Under the PLA Register

RADAR 2 SAILOR VHF ECHO SOUNDER AIS GEN SET X2

LOA 23Mtr

Beam 8 Mtr

Draft 3.2 Mtr

 14T GALLEY MESS 4 BUNKS 2FWD 2 AFT

Damen stan Launch

£35.000.00 as is where is.

SOLD SOLD SOLD SOLD

  This vessel is afloat on the Thames asking Price is £35.000.00 as is where is.

She was built in 1982,

LOA 15.2m

BEAM 5.2m

Draft 1.3

Main Engine Cummins 180hp

CAT- MCA work boat code

Road Transportable

Pushy Cat

£110.000.00

This vessel is afloat on the Thames asking sold  as is where is.                                                                       She was built in 2011,

LOA 15.2m

BEAM 5.2m

Draft 1.3.5 BP

 Main Engine CAT 270 HP

MCA cat 3 work boat code

RADAR CHART PLOTTER ECHO SOUNDER GPS AIS GEN SET X1

Rhina Class Tug

£195,000.00

Year of build 1958

LOA  22Mtr

Beam 6.5Mtr

Draft 2.4Mtr

BP 10 T

Engine CAT D379 750hp

Class RHINA

Electronics CHART PLOTTER RADAR SART EPIRB ECHO SOUNDER RADIO TELEPHONE 2X VHF AIS

Additional INFO    6 BERTHS ALL FORWARD GALLEY MESS
